True TBR36-PTSZ1 - 1 Door Pass-Through Back Bar Fridge 914mm 350L
With a door on the front and another on the back, the True TBR36-PTSZ1 lets staff restock from the cellar or storeroom side while bartenders serve from the other. It is a single-section pass-through, 914 mm wide and 881 mm high, with 350 litres of gross space (about 228 cans or 150 bottles) held at 0.5°C to 3.3°C for beer and soft drinks. Unlike the reach-in TBR32-RISZ1, both faces open, and you can have glass or solid doors front and rear in a black or stainless steel finish.
Key features:
- Pass-through design with one door at the front and one at the rear
- Forced-air refrigeration for quick pull-down and cold serving temperatures
- Front-breathing: True specifies zero clearance at the back and sides
- Doors hinged on the left as standard, field reversible to the right
- Locks standard
- 3 adjustable heavy-duty PVC-coated shelves, 394 x 458 mm
- Stainless steel interior and countertop
- TruLumina LED lighting with 14 colour options on glass-door versions; LED lighting on solid-door versions
- True's patented RCU feature, R290 refrigerant and automatic defrost
Specifications:
- Model: True TBR36-PTSZ1 (PT = pass-through; L-B or L-S = left-hand system with black or stainless exterior; G-G = glass doors or S-S = solid doors front and rear; 2 = 220–240 V)
- Capacity: 350 litres gross, about 228 x 330 ml cans or 150 bottles (True's estimate)
- Dimensions: 914 W x 631 D x 881 H mm (True spec sheet)
- Weight: 121 kg (black solid-door version: 110 kg)
- Temperature range: 0.5°C to 3.3°C (SZ1)
- Refrigerant: R290
- Power: single-phase 220–240 V, 50–60 Hz, 1.8 A running current, 414 W, supplied with a 3.04 m power cord
- Energy use (solid-door versions): 0.635 kWh per 24 hours, 232 kWh per year, tested to EN ISO 22044
- Shelves: 3 supplied, 394 x 458 mm, with 730 mm of internal net height
- Black exterior: black powder-coated steel front, black coated aluminium sides and rear, stainless steel countertop
- Stainless exterior: stainless steel front and countertop, aluminium sides and rear
- Supplied with levelling screws; castors optional, sold separately
- Packed size for delivery: 1083 x 801 x 1067 mm, 132 kg (black solid-door version: 121 kg)
Good to know before you buy:
- Fit: True's spec sheet gives a 631 mm depth that excludes 35 mm for the front handle and 35 mm for the rear handle, so allow about 701 mm overall. The height excludes 7 mm for the levellers. True's catalogue table lists it as 684 mm deep, so ask us for the spec sheet before you finalise joinery.
- Access: packed, it is 1083 x 801 x 1067 mm. Delivery is by tailgate truck to the front of your premises; standard delivery does not include bringing it inside, up stairs or unpacking.
- Glass or solid doors: glass lets you and your customers see stock at a glance; solid doors hold the cold better and keep stock out of sight.
- Power: single-phase 220–240 V, 1.8 A running current, 3.04 m power cord.
- Pricing: This model is priced on application. Ask us for a quote.
Compare similar models:
- True TBR32-RISZ1: single-door reach-in (front door only), 813 mm, 290 litres
- True TBR60-PTSZ1: two-section pass-through, 1524 mm, 550 litres, with a sliding glass door option
- True TBR48-RISZ1: two-door reach-in, 1219 mm, 440 litres
Common questions:
Where would I use a pass-through bar fridge?
Anywhere stock is loaded from one side and served from the other, such as between a back-of-house store and the bar. Each side has its own door, so restocking does not get in the way of service.
Are the rear doors the same as the front?
Yes. Each version has matching doors: glass front and rear, or solid front and rear.
Can I store red wine in it?
This is the SZ1 model, fixed at 0.5°C to 3.3°C for beers, soft drinks, juices and milk. True makes wine-temperature versions, but the range has to be chosen when ordering and cannot be adjusted later. Ask us.
See all our bar fridges.
Warranty: True 5-year parts and labour warranty, including the compressor.
