Atosa WDF157Z - Four Tier Cake Showcase

Atosa WDF157Z - Four Tier Cake Showcase

With four tiers across 1500mm, the Atosa WDF157Z gives bakeries and dessert venues 638 litres of chilled, square glass display. It holds 0°C to +8°C, lights the range with LEDs and uses heated glass to stop fogging. It has one more tier and 141 litres more than the 3 level DF157F, and sits between the WDF127Z and the WDF177Z in the four tier range.

Key features:

• 1500mm of square glass with 4 display tiers (3 glass shelves plus the base)
• 638 litres of chilled display
• Holds 0°C to +8°C, rated for rooms up to 43°C
• Heated glass to remove condensation
• LED lighting
• Italian digital controls and a SECOP compressor
• Sliding rear doors that lift out for cleaning
• Castors fitted, MEPS approved

Specifications:

• Model: Atosa WDF157Z
• Capacity: 638 litres
• Dimensions: 1500 W x 750 D x 1350 H mm
• Weight: 298 kg
• Temperature range: 0°C to +8°C
• Maximum room temperature: 43°C
• Refrigerant: R290
• Power: 820W, 220–240V, 50Hz
• Shelves: 3 glass shelves plus the base, up to 30 kg per shelf
• Packed size for delivery: 1560 W x 800 D x 1500 H mm, 340 kg

Good to know before you buy:

• Access: it arrives packed at 1560 x 800 x 1500mm and 340 kg, by tailgate truck to the front of your premises. Standard delivery doesn't include bringing it inside, so plan the route and the people or equipment to move it.
• First start: stand it upright for 24 hours if it was tilted in transit, then run it empty for 2 hours.
• Power: plug it into its own earthed single-phase 220–240V power point.
• Clearances: allow at least 200mm around it and keep it away from heat sources.

Compare similar models:

• Atosa WDF127Z: 1200mm four tier showcase, 505 litres
• Atosa WDF177Z: 1700mm four tier showcase, 730 litres
• Atosa DF157F: 1500mm square showcase with 3 levels, 497 litres
• Atosa DF157D: 1500mm curved glass showcase with 4 levels, 520 litres

Common questions:

Square four tier or curved four tier?
At 1500mm, the WDF157Z (square glass) holds 638 litres, while the curved glass DF157D holds 520 litres. Both have 4 levels and stand 1350mm high.

How much power does it use?
It is rated at 820W on 220–240V single-phase power, and Atosa recommends its own earthed socket.

Can I move it to clean?
Yes. It has castors, and the sliding rear doors can be removed for cleaning.

See all our cake and sandwich display fridges.

Warranty: 2 years parts and labour, plus an extra 2 years on parts when you register the unit online with Simco.
