FED Thermaster GN3100TNC - Pass-Through Refrigerated Island Counter 1795mm
FED Thermaster GN3100TNC - Pass-Through Refrigerated Island Counter 1795mm
SKU: GN3100TNC
Prefer to talk? Call 0447 483 035 Mon–Fri, 9am–5pm (Sydney time)
- Australia-wide delivery, usually 2–5 business days to Sydney, Melbourne, Brisbane and Adelaide. Delivery info
- Price-Beat Guarantee. Found it cheaper? Send us the link
- Warranty: 2 years parts and labour, plus an extra 2 years on parts when you register the product with FED within 14 days of invoice. Warranty claims
- Tax invoice with our ABN for every order
- Secure checkout
Before it arrives
- Size: 1795 W x 700 D x 860 H mm. Check doorways and access on the way in.
- Weight: 134 kg. Delivered by tailgate truck to your door, so plan for help or a trolley to move it inside.
- Power: 300W, 240V, 10 A.
We supply the equipment only. Connection and installation are by your own licensed trades. Full specifications are in the product details below.
Product details
FED Thermaster GN3100TNC - Pass-Through Refrigerated Island Counter 1795mm
Built for the centre of a busy kitchen, the FED Thermaster GN3100TNC is a 1795mm pass-through refrigerated counter with three solid doors on each side (2 x 3) and 324 litres gross for GN 1/1 pans. Cooks and plating staff can work from opposite sides and reach the same stock. It is made from AISI 304 stainless steel inside and out, holds -2°C to +8°C, and is rated to 40°C room temperature. The GN2100TNC is the shorter 1360mm version.
Key features:
- Pass-through design with three solid doors on each side (2 x 3)
- Takes GN 1/1 size pans
- Ventilated refrigeration for even air circulation
- Electronic thermostat with digital LED temperature display
- Auto defrost and automatic evaporation of condensate water
- Heating element hidden in the door frame to stop condensation
- 60mm insulation, self-closing doors and tool-free replaceable magnetic gaskets
- AISI 304 stainless steel inside and out, with rounded internal edges
Specifications:
- Model: FED Thermaster GN3100TNC
- Capacity: 324 litres gross
- Dimensions: 1795 W x 700 D x 860 H mm
- Weight: 134 kg
- Temperature range: -2°C to +8°C
- Maximum room temperature: 40°C at 40% relative humidity
- Power: 300W, 240V, 10 A
- Doors: 2 x 3 hinged solid doors (three each side)
- Construction: AISI 304 stainless steel inside and out
- Packed size for delivery: 1825 x 730 x 910 mm
Good to know before you buy:
- Layout: as an island counter it needs working room and door clearance on both sides.
- Access: the carton is about 1825 x 730 x 910 mm and the unit weighs 134 kg. It is delivered by tailgate truck to the front of your premises, and standard delivery doesn't include bringing it inside, up stairs or unpacking.
- Power: runs on 240V and FED lists it at 10 A.
Compare similar models:
- FED Thermaster GN2100TNC: shorter 1360mm island counter, 2 x 2 doors, 216 litres
- FED Thermaster PA3100TNC: 2020mm pass-through counter for 400 x 600mm shelves, 580 litres
- FED Thermaster GN3100DT: 1795mm triple-door dual temp GN counter fridge/freezer
Common questions:
How many doors does it have?
Six in total: three on each side.
Why is there a heater in the door frame?
FED fits a concealed heating element in the door frame to eliminate condensation around the doors.
What temperature does it hold?
-2°C to +8°C.
See all our undercounter fridges.
Warranty: 2 years parts and labour, plus an extra 2 years on parts when you register the product with FED within 14 days of invoice.
