Tecnodom TD-10NE - Nerone MID 10 Tray Digital Combi Oven, 600x400 or GN 1/1

Tecnodom TD-10NE - Nerone MID 10 Tray Digital Combi Oven, 600x400 or GN 1/1

The Tecnodom Nerone MID TD-10NE is the largest oven in the Nerone MID range: an Italian-made, 10 tray electric combi oven that takes 600 x 400 mm bakery trays or GN 1/1 pans. It cooks by convection from 30°C to 280°C, with or without water injection, giving restaurants, bakeries and caterers the capacity to roast, bake and steam large batches in one oven. Compared with the 6 and 7 tray models, its 840 mm tall chamber holds ten levels at 80 mm spacing.

Key features:

• 100% made in Italy
• Takes 10 x 600 x 400 mm trays or 10 x GN 1/1 pans, 80 mm apart
• Digital controls, 30°C to 280°C
• Convection cooking with or without water injection (steam)
• Manual or automatic water injection, with adjustable water dosage
• Electric, three-phase 12.7 kW
• Grids and pans not included

Specifications:

• Model: Tecnodom TD-10NE (Nerone MID)
• Capacity: 10 x 600 x 400 mm or 10 x GN 1/1
• Tray spacing: 80 mm
• Temperature: 30°C to 280°C
• Oven chamber: 680 W x 480 D x 840 H mm
• Dimensions: 840 W x 910 D x 1150 H mm
• Weight: 125 kg
• Power: 12.7 kW, 380–415V three-phase plus neutral
• Water: 3/4 inch mains connection, 1.5–2.5 bar; drain with 30 mm siphon
• Packed size for delivery: up to 880 x 995 x 1300 mm, 150 kg

Good to know before you buy:

• Power: three-phase 415V; the power cable and three-phase plug are not included. It must be connected by a licensed electrician. We supply the equipment only.
• Water / drain: the steam function needs mains water through a shut-off valve and a 30 mm siphon drain, connected by a licensed plumber. Tecnodom recommends a softener to keep hardness below 3°F; scale damage from untreated water is not covered by the warranty.
• Clearances: keep at least 100 mm from the sides and back of the oven.
• Access: the packed oven is about 150 kg and 1300 mm tall. It is delivered by tailgate truck to the front of your premises, so plan how to get it inside.

Compare similar models:

• Tecnodom TD-7NE: 7 trays, 10.7 kW
• Tecnodom TD-6NE: 6 trays, 7.65 kW
• Tecnodom TDC-10VH: Nerone CL 10 tray with 100% steam, multi-sensing core probe and automatic cleaning

Common questions:

MID or CL: what's the difference?
Both are 10 tray Tecnodom combis. The CL (TDC-10VH) adds a 100% steam mode, multi-sensing core probe, 99 programmable recipes and automatic cleaning. The MID is the simpler convection-plus-water-injection oven.

Does it come with trays?
No. Grids and pans are not included. Ask us about trays to suit.

Do you install it?
We supply the equipment only. It must be connected by a licensed electrician (three-phase) and a licensed plumber (water and drain) in your area.

See all our commercial combi ovens.

Warranty: 1 year parts and labour (FED).
