Williams Glass Chiller GC2UGDSL / GC2RGDSL - 2 Door Spring Loaded Glass Chiller 1727mm

Williams Glass Chiller GC2UGDSL / GC2RGDSL - 2 Door Spring Loaded Glass Chiller 1727mm

The Williams Glass Chiller GC2UGDSL gives a high-volume bar two spring-loaded stacks of cold glasses side by side, each lift raising the next full basket to the top as the one above empties. Designed and built in Australia, the 1727mm two-door cabinet takes three standard baskets per door, holds +1°C to +4°C in rooms up to 40°C and plugs into a 10 amp outlet. The GC2UGD is the shelf-loading version of this cabinet, the GC25UGDSL is the spring-loaded model for 500 x 500mm baskets, and the GC2RGDSL is the remote cabinet for venues with a central condensing unit.

Key features:

• Two spring-loaded lifting cages, one per door, that raise the basket stack as glasses are taken
• Rapidly chills beer glasses for quick bar service
• Holds +1°C to +4°C, designed for a 40°C ambient
• Takes three glass baskets per door (355 x 355mm or 355 x 431mm, not included), based on 150mm high glasses
• Self-closing triple-glazed glass doors and a polycarbonate night lid
• Adjustable electronic controller with digital temperature display
• Forced-air refrigeration with auto defrost
• Stainless steel interior and exterior (excluding rear and underside)
• On 120mm castors with 150mm adjustable legs supplied loose, plinth-mount ready face-mounted hinges

Specifications:

• Model: Williams GC2UGDSL (self-contained) or GC2RGDSL (remote)
• Capacity: 3 glass baskets per door (6 in total), baskets not included, based on 150mm high glasses
• Basket sizes: 355 x 355mm or 355 x 431mm
• Loading: 2 spring-loaded lifting cages (1 per door)
• Dimensions, self-contained: 1727 W x 600 D x 845 H mm on 120mm castors
• Dimensions, remote: 1327 W x 600 D x 875 H mm on 150mm legs
• Weight: 140 kg (self-contained), 100 kg (remote)
• Temperature range: +1°C to +4°C
• Maximum room temperature: 40°C
• Refrigerant: R134a (self-contained), R448A (remote)
• Power: 10 amp plug with 2 m cable, 4.0 A running current (self-contained), 0.5 A (remote)
• Remote refrigeration duty: 750 W at -5°C SST
• Doors: 2 self-closing triple-glazed glass doors
• Finish: stainless steel interior and exterior, excluding rear and underside
• Origin: designed and built in Australia

Good to know before you buy:

• Access: 1727mm long, 600mm deep, 845mm high on castors and 140 kg for the self-contained unit. Delivered by tailgate truck to the front of your premises; allow two people to move it to the bar.
• Power: standard 10 amp power point, 2 m cable.
• Baskets: not included. Each spring cage takes three 355 x 355mm or 355 x 431mm baskets.
• Remote version: the GC2RGDSL comes without a condensing unit. It is fitted with the evaporator, TX valve, controller, plug, junction box and condensate drain. Your refrigeration mechanic supplies and installs a condensing unit for 750 W at -5°C SST on R448A, plus pipework and controls (no solenoids supplied). Williams can advise on sizing. We supply the equipment only.
• What it is for: a glass chiller for glassware, not a food fridge.

Compare similar models:

• Williams GC2UGD: the same two-door chiller with two shelves per door instead of spring lifts
• Williams GC1UGDSL: one-door spring-loaded model, 1021mm wide
• Williams GC25UGDSL: two-door spring-loaded model for 500 x 500mm baskets, 2017mm wide
• Williams FGC2: slimline two-door glass chiller with a top-loading sliding lid

Common questions:

Can I mix shelf and spring loading in one cabinet?
Not on this model. The GC2UGDSL has a spring-loaded cage behind each door. If you prefer shelves, the GC2UGD is the same cabinet with two adjustable shelves per door.

What does the remote GC2RGDSL come with?
The cabinet, both spring cages, the evaporator, TX valve, controller, fitted plug, junction box and condensate drain. The condensing unit, pipework and controls are supplied and installed by your refrigeration mechanic.

Do you install it?
We supply the equipment only. The self-contained GC2UGDSL plugs into a 10 amp outlet. The remote GC2RGDSL must be connected to a condensing unit by a licensed refrigeration mechanic in your area.

See all our bar freezers.

Warranty: Williams 24-month parts and labour warranty on the self-contained GC2UGDSL, from the date of invoice, carried out by Williams authorised service agents on the Australian mainland. The remote GC2RGDSL carries 12 months parts only. Warranty repairs must be logged with Williams first.
