The Fagor WHC-502TRCBD is the heat recovery version of the iNova pass-through dishwasher. At the end of each cycle it uses the machine's own heat to warm the incoming cold water from about 10°C to 25°C, which cuts energy use, releases less steam into the kitchen and helps glasses and plates dry faster. FED says it can be installed without an external exhaust hood (subject to conditions), so it suits restaurants, hotels and clubs where adding a canopy is hard.

Key features:

• Energy recovery system runs for 40 seconds (configurable) at the end of each cycle, pre-heating incoming water from 10°C to 25°C
• Less steam when the hood opens, for a cooler, more comfortable work area and faster drying
• FED states no external exhaust hood is needed, subject to compliant background ventilation and site approval
• 500 x 500 mm baskets at up to 40 per hour; 90, 120 and 180 second cycles plus an extended 480 second cycle
• Washes at 60°C and rinses at 85°C, with a 33 litre tank (3 kW) and 750 W wash pump
• Drain pump, peristaltic detergent dispenser and hydraulic rinse aid dosing, with chemical dosing control
• Duo-KLIP wash and rinse arms, soft-start dual-flow pump, volumetric rinse and double-stage filtration
• Hood slides on metal runners; set up in a line or a corner, working in either direction
• LED displays with error codes and a magnetic switch that stops the cycle if the hood is lifted

Specifications:

• Model: Fagor WHC-502TRCBD
• Basket size: 500 x 500 mm
• Clearance: 450mm for plates, 415mm for glasses
• Output: up to 40 baskets per hour (energy recovery adds about 30 seconds per cycle)
• Wash tank: 33 litres, 3 kW
• Dimensions: 630 W x 750 D x 1975 H mm
• Weight: 117 kg
• Power: 9.75 kW, 415V three-phase plus neutral (3N~), 16.3 A
• Water supply: cold water at 200–400 kPa, maximum 25°C (15–25°C recommended), 3/4 inch connection
• Supplied: 1 dish basket, 1 glass basket and 1 cutlery basket
• Packed size for delivery: 765 x 905 x 1770 mm, 138 kg

Good to know before you buy:

• Ventilation: FED's no-exhaust-hood claim is subject to compliant background ventilation, site mechanical approval, and Fagor's set-up and maintenance requirements. Check with your ventilation designer or local authority before you rely on it.
• Water: it needs a cold water connection (Fagor recommends 15°C to 25°C), made by a licensed plumber along with the drain. We supply the equipment only.
• Power: 415V three-phase, connected by a licensed electrician. FED's brochure lists it as available in three-phase only.
• Height: at 1975mm tall, check your ceiling height and doorways on the way in.

Compare similar models:

• Fagor WHC-502TBD: the same iNova pass-through design without heat recovery, 1480mm high
• Fagor WUC-502TBD: front-loading undercounter model with 500 x 500 mm baskets
• Asber GEX-H500BDD: Easy Line pass-through dishwasher

Common questions:

Do I need an exhaust canopy over it?
FED says no external exhaust hood is required, provided there is compliant background ventilation and site mechanical approval, and Fagor's set-up and maintenance requirements are met. Confirm with your ventilation designer or council.

Can I connect it to hot water?
No. The heat recovery system warms the incoming water, so Fagor recommends a cold water supply between 15°C and 25°C, with a maximum of 25°C.

Do you install it?
We supply the equipment only. It must be connected by a licensed plumber and a licensed electrician.
